Voopoo VMATE Max Vape Kit

VOOPOO VMATE Max Pod Kit – 1200mAh | 5–30W Adjustable Output

The VOOPOO VMATE Max is a compact yet solid zinc-alloy pod device powered by a 1200mAh internal battery with adjustable output from 5W up to 30W. It features the GENE chipset, Hidden Horizon Screen and side Gem-like LED light bars.

The device uses the dedicated VMATE Cartridge family (V2 / Top-Fill versions) and is not compatible with PnP or Argus pod platforms.

Short Technical Intro

VMATE Max combines adjustable power, durable zinc-alloy construction and intelligent chipset control. Compared to lighter plastic pod systems, it has a more substantial weight and rigid build quality.

Quick Technical Summary

• Activation: Auto-draw + Fire button
• Battery: 1200mAh internal
• Power Range: 5W–30W adjustable
• Display: Hidden Horizon Screen
• Light Effects: Dual Gem-like LED side bars
• Charging: USB-C, 5V/2A fast charging
• Pod Capacity: 2ml (EU TPD)
• Included Cartridges: 0.4Ω + 0.7Ω VMATE Top-Fill
• Static Wick Saturation Time: 5 minutes

What’s in the Box

• 1 × VOOPOO VMATE Max Device (1200mAh)
• 1 × 0.4Ω VMATE Top-Fill Cartridge (2ml EU)
• 1 × 0.7Ω VMATE Top-Fill Cartridge (2ml EU)
• 1 × USB-C Charging Cable
• 1 × User Manual

Box contents may vary by batch.

Heating Element Status

Heating Element: Integrated Coil Cartridge System — VMATE Cartridges (full cartridge replacement required).

Activation & Control

• Auto-draw supported
• Fire button supported
• Adjustable wattage (5W–30W)
• Three output modes: SPT (Sport), NOR (Normal), ECO
• Hidden Horizon Screen interface
• Rear airflow slider
• Gem-like LED visual indicators

Pod Filling Protocol – Top-Fill System

• Open the top silicone fill port (no need to remove cartridge)
• Insert bottle nozzle into fill port
• Avoid central airflow chimney
• Close stopper firmly
• Wait full saturation time before first use

Static Wick Saturation Time

Static Wick Saturation Time: 5 minutes after first fill.

E-Liquid Compatibility Guidance

0.4Ω Cartridge (High Output / RDL – up to 30W):

• ✔ Recommended: 60–70VG
• ⚠ Not recommended for high-strength nicotine salts at full 30W

0.7Ω Cartridge (MTL / Smooth RDL):

• ✔ Recommended: 50/50 VG/PG
• ✔ Suitable for nicotine salts

Viscosity Note (Ireland): VG thickens below 10°C. Extend priming time and allow device to reach room temperature before use.

Hardware Specification Matrix

Compatibility Last Verified

Compatible exclusively with VOOPOO VMATE Cartridge V2 / Top-Fill series. Not compatible with PnP, Argus, Vinci or XROS pod systems.

Safety Features

• Short-circuit protection
• Over-temperature protection
• Low-voltage protection
• 8-second cut-off

FAQ

Document Update Notice:
This product description was last reviewed and updated on 16 February 2026.
