VOOPOO Drag 4 Mod
Regular price:
product unavailable
Description
VOOPOO Drag 4 Mod – Dual 18650 Regulated Platform (GENE.TT 2.0)
VOOPOO Drag 4 Mod is a dual-battery regulated device built around the GENE.TT 2.0 chipset, designed for high-power sub-ohm systems and advanced 510 atomiser platforms. The device uses two external 18650 cells and provides controlled output across a wide wattage range with multi-layer protection logic.
This product is a mod only (no tank in this listing context). Tank and coil performance will depend on the attached 510 atomiser, coil specification and liquid viscosity.
Hardware Specification Matrix
| Hardware Category | Specification | Engineering Notes |
|---|---|---|
| Chipset | GENE.TT 2.0 | Regulated output control + protection suite |
| Battery Architecture | 2 × 18650 (external, not included) | Use matched, high-drain cells in good condition |
| Power Output Range | 5W – 177W | Maximum output depends on batteries and atomiser load |
| Output Voltage | 3.2V – 8.4V | Dual-cell series output ceiling |
| Supported Resistance | 0.05Ω – 3.0Ω | Lower resistances increase current demand |
| Modes | SMART / RBA / ECO / TC | TC supports common wire types per manufacturer implementation |
| Charging Interface | USB-C (5V / 3A) | Fast charging supported; external charger recommended for routine use |
| Thread | 510 (spring-loaded) | Compatible with standard 510 tanks / RDAs / RTAs |
| Materials | Zinc alloy + leather + wood/resin (variant dependent) | Finish differs by colourway |
| Form Factor | Approx. 89mm × 52.4mm × 25.4mm | Tank overhang depends on atomiser diameter |
Performance Indicators
Power Headroom (Dual 18650): ■■■■■
Chipset Regulation Stability: ■■■■□
Battery Autonomy (typical use): ■■■■□
Thermal Margin at High Wattage: ■■■■□
User Interface Readability: ■■■■□
Technical Pairing Notes (VG/PG Mapping)
Drag 4 is typically paired with sub-ohm tanks and mesh coils. The liquid viscosity should be matched to coil airflow and wicking throughput:
- 0.15Ω – 0.25Ω (higher wattage sub-ohm): recommended 70VG / 30PG
- 0.3Ω – 0.4Ω (mid sub-ohm / restricted DL): 60VG / 40PG or 70VG / 30PG
- 0.6Ω+ (lower power builds): 50VG / 50PG compatible, depending on atomiser design
Cold climate note (Ireland): when ambient temperature drops below ~10°C, higher VG liquids thicken; allow the tank to warm slightly and avoid immediate long draws after filling.
Safety & Regulatory Context (Ireland)
For adult users (18+) in Ireland. This is a battery-powered device intended for use with compliant e-liquids and compatible 510 atomisers. Follow battery safety best practices (undamaged wraps, matched pair usage, correct polarity) and dispose of cells and electronics via appropriate WEEE channels.
Intent Discloser: This text is technical product documentation for device selection and safe configuration. No health or cessation claims are made.
FAQ
No. Drag 4 is designed for two external 18650 batteries. The device supports a regulated power range of 5W to 177W, depending on battery condition and atomiser load. Yes. The device supports USB-C charging up to 5V/3A. For long-term cell lifecycle, an external charger is recommended. Technically yes at low wattage, but the platform is primarily designed for higher power 510 setups. For dedicated MTL, a smaller low-power device may be more practical.Does VOOPOO Drag 4 use 21700 or 20700 batteries?
What is the maximum power output?
Is USB-C fast charging supported?
Can I use MTL tanks on Drag 4?
Last Updated: February 2026
