Innokin EZ Tube Vape Kit

Innokin's stylish tube kit for MTL and RDL - the EZ Tube Mod with the Zenith Minimal Tank

With the EZ Tube Kit, Innokin presents its new kit for a flavorful MTL and RDL vaping experience. With its round shape and pleasantly non-slip surface, the stylish EZ Tube Mod sits comfortably in the hand and is extremely comfortable to use. The straight and modern design as well as the trendy color variants make it a real eye-catcher that can accommodate atomizers with a base diameter of up to 24.0 mm on its spring-loaded 510 connection. The Zenith Minimal tank atomizer is the perfect match for the EZ Tube Mod and creates an absolutely harmonious visual symbiosis with it. The finished coil tank impresses with its great MTL and RDL performance as well as its uncomplicated handling.

Fantastic to use and with a brilliant OLED display – the EZ Tube Mod

The integrated and powerful 2100 mAh battery gives the EZ Tube Mod an output power of up to 40 watts and can be quickly recharged via the side USB Type-C port with a charging current of up to 1.5A. The power is adjusted via a knurled ring at the bottom of the tube mod. With each rotation of the ring, you can feel and hear it click into the next position and the power changes in steps of 0.5 watts. On the bottom of the tube is the compact and brilliant OLED monochrome display, which shows relevant information such as battery level, performance and draw time. A 360° LED color ring around the dial also provides visual information in various RGB colors about the operating status and battery level of the stylish tube mod (green = over 30%, yellow = 10-30%, red = under 30%). Activation and other operation is carried out conveniently using the ergonomic fire button (3-click on/off, 2-click power setting). A 15-second overtime protection as well as protection against short circuits, overheating and excessive resistance guarantee an always safe and untroubled vaping experience.

The Zenith Minimal Tank for maximum vaping enjoyment

The Zenith Minimal Tank holds up to 2.0 ml of liquid in its borosilicate glass tank. A comfortable top fill underneath the top cap, which has a practical bayonet lock, makes the refueling process pleasantly easy. The scope of delivery already includes various and interchangeable 510 drip tips for MTL and RDL and your own 510 drip tips can also be combined with the high-quality tank evaporator. The continuously adjustable bottom AFC with a wider air inlet slot and 3 individual holes allows for quick and precise adjustment of the airflow from strict MTL to RDL draft behavior. The coil is changed using a quick push & pull system and the Zenith Minimal Tank is compatible with the coils from Innokin’s popular Z series. The scope of delivery already includes a 0.8 ohm Z-coil for classic mouth-to-lung vaping with powers between 15 and 18 watts and a 0.3 ohm Z-coil for RDL vaping with powers of 30 to 40 watts. The Z-Coils offer an intense taste experience with dense vapor and impress with their great overall performance and long service life.

Data

• Powerful tube kit for MTL and RDL
• EZ Tube Mod
• Modern and ergonomic tube design
• Pleasant surface structure
• High-quality material mix
• Convenient operation
• Material: aluminum alloy
• Integrated 2100 mAh battery
• USB Type-C charging with up to 5V / 1.5A
• Output power: 6 to 40 watts
• Output voltage: 1.0 to 7.5 volts
• Resistance range: 0.3 to 3.5 ohms
• Activation via the ergonomic fire button
• 3-click on/off
• 2-click power adjustment
• Power selection in 0.5 watt steps via a rotating 360° ring at the bottom of the tube
• 360° RGB LED ring for visual display of operating status and battery level
• Brilliant and compact OLED display on the bottom of the Tube Mod to display battery level, power and train duration
• All relevant protection circuits on board
• Standard 510 connection for atomizers up to 24.0 mm base diameter
• Zenith Minimal tank vaporizer
• Material: stainless steel & borosilicate glass
• 2.0 ml tank volume
• Top fill
• Top cap with bayonet closure
• Infinitely adjustable bottom AFC with a wider air inlet slot and three individual holes
• Interchangeable 510 drip tips for MTL and RDL
• Compatible with Innokin’s Z-Coil series
• Fast push & pull coil change
• MTL Z-Coil 0.8 Ohm (15-18 W) and RDL Z-Coil 0.3 Ohm (30-40 W) already included
• Standard 510 thread
• 24.0 mm base diameter

Dimensions

• Length: 136.0 mm including tank / 90.0 mm without tank
• Diameter: 25.0mm

Scope of delivery

• 1 x Innokin EZ Tube Mod battery carrier
• 1 x Innokin Zenith Minimal Tank
• 1 x Innokin MTL Z-Coil 0.8 Ohm (pre-installed)
• 1 x Innokin RDL Z-Coil 0.3 Ohm
• 1 x replacement tank glass, 4.0 ml
• 1 x 510 MTL Drip Tip
• 1 x 510 RDL Drip Tip
• 1 x O-ring set
• 1 x USB Type-C charging cable
• 1 x Tutorial QR Card
• 1 x Warning Notices
• 1 x Quick Start Guide
